Compressor Danfoss Maneurop NTZ068A4LR1A

Kami TIRIS GLOBAL merupakan distributor dan supplier suku cadang pendingin yang menyediakan berbagai merk dan type kompressor ac barang-barang spare part ac serta freon dll. Jual Reciprocating Compressor Danfoss NTZ068A4LR1A 01. Model number ( on compressor nameplate) NTZ068A4LR1A 02. Suction connection 1-1/ 4″ Rotolock 03. Discharge connection 1″ Rotolock 04. Suction connection with supplied sleeve 5/ 8″ ODF 05. Discharge connection with supplied sleeve 1/ 2″ ODF 06. Oil sight glass Threaded 07. Oil equalisation connection 3/ 8′ ‘ flare SAE 08. Oil drain connection None 09. LP gauge port Schrader 10. Internal pressure relief valve 30 bar / 8 bar 11. Cylinders – 12. Swept volume 68.0 cm3/ rev 13. Displacement at 50 Hz 11.8 m3/ h 14. Displacement at 60 Hz 14.3 m3/ h 15. Nominal speed at 50 Hz 2900 rpm 16. Nominal speed at 60 Hz 3600 rpm 17. Nominal voltage at 50 Hz 380-400V/ 3/ 50Hz 18. Nominal voltage at 60 Hz 460V/ 3/ 60Hz 19. Voltage range at 50 Hz 340-440 V 20. Voltage range at 60 Hz 414-506 V 21. Winding resistance ( between phases) 7.11 Ohm 22. Winding resistance ( between phases 1-2) 7.11 Ohm 23. Winding resistance ( between phases 1-3) 7.11 Ohm 24. Winding resistance ( between phases 2-3) 7.11 Ohm 25. Main winding resistance – 26. Start winding resistance – 27. Maximum Continuous Current ( MCC) 8.4 A 28. Maximum Must Trip current ( MMT) – 29. Locked Rotor Current ( LRA) 25 A 30. Motor protection Internal overload protector 31. Net weight 23 kg 32. Oil charge 1 litre 33. Oil type POE – 160Z 34. Approved refrigerants R404A, R507A 35. Refrigerant charge limit 3 kg 36. Approvals ( CE) CE certified 37. Approvals ( UL) UL certified ( file SA6873) 38. Approvals ( CCC) – 39. Maximum system test pressure LP side 25 bar( g) 40. Maximum system test pressure HP side 30 bar( g) 41. Maximum differential test pressure 30 bar 42. Maximum number of starts per hour 12 43. Packaging Singlepack 44. Pack quantity 1 45. Parts shipped with compressor Suction & Discharge solder sleeves, rotolock nuts and gaskets Dengan Diisi Oleh Para Profesional Handal Kami Selalu Memberikan Pelayanan Dan Penawaran Terbaik Kami, Kami Selalu Menjadi No.1 Dalam Penyediaan Kompresor Ac Yang Anda Butuhkan. Info Produk & Order Hubungi : TIRIS GLOBAL INDONESIA Gd. LTC Glodok Lt.2 Blok C19 No.5 Jl. Hayam wuruk 127 – Jakbar Phone : 021-6220 1432 Mobile : 0877 2182 5252 // 0812 8692 5252 ( Call / WA ) Website : tirisglobal.com tags : jual compressor AC, harga compressor murah, kompresor AC Jakarta, distributor compressor AC, jual compressor ac Danfoss, agen compressor murah, compressor ac glodok, kompresor AC, compressor Danfoss Indonesia, compressor Danfoss terlengkap, jual kompresor, supplier compressor Danfoss, sparepart compressor Danfoss, jual compressor murah, harga compressor Danfoss, compressor Danfoss bekasi, compressor Danfoss depok, compressor Danfoss tangerang, compressor Danfoss bogor, jual compressor Danfoss
